Air Tight Double Glass Aluminum Flush Door Outer Window Screen Integrated

Place of Origin GUANGDONG,CHINA
Brand Name KLUK
Certification ISO9001:2021;ISO14001:2021
Model Number KSC
Minimum Order Quantity 500 Square Meters
Price Negotiation
Packaging Details Pearl cotton, foam cotton, plywood paper, film, wooden box
Delivery Time 20-30 days
Payment Terms T/T, L/C, D/P
Supply Ability 30000 Square Meters

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Materials Aluminum Alloy+Glass Glass Clear Double Tempered Glazeing
Thickness 1.5-2.0mm Color Black/grey Powder Coated
Accessory Chinese Top Brand/Europe Brand Size Customized Size,OEM
High Light

Double Glass Aluminum Flush Door

,

Air Tight Aluminum Flush Door

,

OEM Aluminum Flush Door

Leave a Message
Product Description

GDM120 Series Outer Window Screen Integrated Air Tight Aluminum Flush Door







Specification:



1. The fixed part adopts arc pressing line;

2. Double air tight design ensures the watertight and air tight performance of the whole door;

3. Window screen body design, anti mosquito, ventilation and complete functions;

4. At the same level, the energy-saving effect of the whole door is better;

5. 6mm + 12a + 6mm insulating glass is standard.





Advantages of Broken Bridge Aluminum:




Good thermal insulation. It adopts the soft combination of inner and outer frames of thermal insulation profiles, and the frame adopts the three sealing form of one rubber strip and two wool strips, which is tightly closed, with excellent air tightness, water tightness and thermal insulation performance; The window sash adopts hollow glass structure, which makes the window truly show excellent sound insulation, heat insulation, heat preservation and function, and greatly saves heating and cooling costs. The heat transfer coefficient K value is tested to be less than 2.23-2.94w / ㎡ · K, which has remarkable energy-saving effect. The energy-saving costs in recent years are enough to make up for the investment in the early stage.
2. Broken bridge aluminum waterproof function. The structural drainage system is designed based on the principle of pressure balance. The slope step type is designed for sliding. The drainage outlet is set, which has smooth drainage and good water tightness.
3. Anti condensation and frost of broken bridge aluminum. The broken bridge aluminum profile can realize the three-way sealing structure of doors and windows, reasonably separate the water vapor chamber, successfully realize the equal pressure balance of gas and water, significantly improve the water tightness and air tightness of doors and windows, and achieve the effect of clean and bright windows.
4. Broken bridge aluminum anti mosquito screen window design. The invisible screen window can be installed inside and outside. It has the function of preventing mosquitoes and flies. It is especially suitable for areas with many mosquitoes in the north.
5. Broken bridge aluminum anti-theft and anti loosening device. Equipped with a unique multi-point hardware lock to ensure the stability and safety of the window in use.
⒍ broken bridge aluminum anti noise and sound insulation. The structure is carefully designed with tight joints. According to the test results, the air sound insulation reaches 30-40db, which can ensure that the residents within 50m on both sides of the expressway are not disturbed by noise, and the adjacent downtown can also ensure the indoor tranquility and warmth.
⒎ broken bridge aluminum fire protection function. Aluminum alloy is made of metal and will not burn.





Performance Parameter National Standard
Wind Load Resistance 4.5<=p3>=5.0 level 9
Air Tightness q1<=0.5 level 8
Water Tightness 250<=△p>=350 level 3
Thermal Insulation / level 5
Sound Insulation 35=<Rw+Ctr<40 level 5




Name/Model: GDM120 Series Outer Window Screen Integrated Air Tight Flush Door
Profiles: 6063-T5 high quality aluminium extrusion profiles
Glass Choice: Low-e; relective;Frosted; tinted; clear tempered glazing
Glass Choice: 5mm; 6mm,12mm single tempered glazing
5+12A+5mm; 5+27A+5mm; 6+12A+6mm double glass
5+6A+5+6A+5mm triple glass
5+0.76+5mm;6+2.28+6mm Laminated
other glass type you need
Color: matt black;white;ultra silver;clear anodized;nature clean aluminium
Any color available
Customized (matt black;white;ultra silver;clear anodized;nature clean aluminium)
white or other color

Hardware :


China Top brand: MACO


Frame Surface Finish: Powder coated meet AS 3715; Electrophoresis; flucarbon; Anodizing;
Flyscreen: Stainless steel security mesh; Aluminium security mesh; Fiberglass flys
Guarantee : Years
Security: Crimsafe mesh ; Grille available
Application: Building(office/hotel/apartment)
